1030 PC Flex Solder Mask 8 oz bottle - Regular Viscosity Premium products

Images are for reference only
See Product Specifications




Our Price: $14.00
Mfg Part Number: 1030

Availability: In Stock
Product Code: 1030_C405
Qty :

Description

PC Flex Mask Regular Viscosity is a green single-component natural latex rubber that cures at room temperature. This material is formulated to resist the adhesion of solder to specified areas of the circuit board during the soldering operation. It will withstand temperatures up to 268C/515F during the normal soldering operation (not to exceed 5 seconds). Once this material is used to mask the circuit board from solder, it is then manually peeled off and discarded. Other applications include sealing molds, masking conformal coating areas and holding components during wave solder.

PC Flex Mask cures in approximately 40 minutes at room temperature (22/72F) and relative humidity of less than 40%. The cure time could vary according to the mask thickness and relative humidity conditions. Optimum thickness would range between 10-30 mils.

PC Flex Mask removes easily by hand or tweezers. Simply lift on corner and pull. A slight lifting action will remove PC Flex Mask all in one piece, leaving no residue. For best results, PC Flex Mask should be removed as soon as possible after the cleaning operation.

Features
  • Has a shelf life of 6 months from date of manufacture
  • Is available in different viscosity and colors.
  • Removes easily by hand or tweezers. Simply lift on corner and pull.
  • Cures in approximately 40 minutes at room temperature
