"OBSELETE REPLACE BY ST1600" PH100 Low Profile IR Preheater for the Most Thermally Challenging PCBs

The PACE PH100 is a high powered (1600W), non-contact infrared heating system with an ergonomic, low-profile design which permits operators to safely pre-heat PCB’s for fast, efficient soldering, rework or repair, even on the highest mass, heat-sinking, lead-free PCB’s.

Rapid, Safe Soldering or Desoldering on High Mass, Heat-Sinking Assemblies

Do you repair thick multilayer printed circuit boards that are connected to metal ground planes? Avionics modules that are designed to dissipate heat? Heat-sinking pcb's utilizing lead-free alloys that seem to require a blow-torch to solder effectively? Then the PH 100 PCB Preheater is for you! The PACE PH 100 is a high powered (1600W), non-contact infrared (IR) underheating system with an ergonomic, low-profile design which permits operators to safely pre-heat PCB’s for fast, efficient soldering, rework or repair, even on the highest mass, thermally challenging, lead-free PCB’s.

Why Use Bottom-Side Preheat?

1. Promotes rapid solder reflow while preventing heat damage and thermal stress or shock
2. Ensures homogenous temperatures across package/PCB
3. Decreases warping & maintains planarity of the rework site
4. Reduces top-side temperature and dwell-time requirements
5. Increases soldering iron tip-life by allowing lower tip temperatures
